here is a rough draft for a t-1 led board that will display midibox not all led positions will be used.I have yet to finish this.A double sided pc board with plated through holes is the best bet ,and leds can be adjusted during installation for straightness.I as yet have not done the top component view (the led orientation) yet as it has not been built yet.
IMG_20180214_0002.pdf
Here is a rough draft of a midi box t-1 led project .THIS IS NOT COMPLETE.NOT all led positions are used.I have a lot of work to do on this yet .The leds can be straightened during soldering and 1 led lead at a time then adjust straightness of led.I do have flasher circuitry ,which is not shown yet also the led orientation is not done yet. regards scottsober 2-15-2018
