Album by jjonas
Gallery category: members-gallery
miscellaneous images relating to midibox stuff
Settings for Elnec SmartProg2 to program PIC18F4685.
These are the settings I used to program MIOS bootloader onto a PIC18F4685 with Elnec SmartProg2.
DIY seppoman pcb
aoutng lisälevy
SSM2044b
overlap
ssm2164 VCA schematic, first draft
SSM2164 VCA, 2nd draft
5x Midi thru (front)
5x Midi thru (back)
5x Midi thru (bottom)
5x Midi thru (top)
5x Midi thru (inside top)
5x Midi thru (inside bottom)
Drawn with Eagle, converted to g-code with pcb-gcode (an Eagle ULP) and routed with a small CNC machine.
Stereo noise gate PCB
MXR stereo noise gate pcb layout with component values
MXR stereo noise gate component values (without comp. names)
Sequencer box (inside)
Sequencer box built inside a cheap Wisent tool box (from a recycling center). Contents: MBSEQv4, MBSIDv2 (with noise gate and SSM2044 filters), two sample players (one for mellotron and drum samples, another one for the drummer’s tempo track), DSI Tetra, EHX V256 vocoder, Waldorf Blofeld, 2x Behringer MX400 mixers.
Sequencer box (inside)
[Image not found: koko-loota.jpg]
